Stainless Steel Pulling Elbows
Submittal Sheet: Pulling Elbow
Downloads
Pulling elbows are designed for use with rigid conduit to provide access at 90° bends and support wire pulling in conduit systems. These fittings help reduce conductor stress and allow straight pulls in either direction during installation and maintenance.
Gibson Stainless manufactures corrosion-resistant stainless steel pulling elbows for demanding industrial environments. Each pulling elbow is supplied complete with a Type 316 SS cover, neoprene gasket, and Type 316 SS screws.
Material:
-Body: CF8M (316 SS)
-Cover and Screws: 316 SS
-Gasket: Neoprene
100% Made in USA
| Part Number | Trade Size | Short Description | Material | |
|---|---|---|---|---|
| PE50 | 1/2 | 1/2" Pulling Elbow | CF8M/316 SS | |
| PE75 | 3/4 | 3/4" Pulling Elbow | CF8M/316 SS | |
| PE100 | 1 | 1" Pulling Elbow | CF8M/316 SS | |
| PE150 | 1-1/2 | 1-1/2" Pulling Elbow | CF8M/316 SS | |
| PE200 | 2 | 2" Pulling Elbow | CF8M/316 SS |
