3/4" Type 316 SS 90° Liquidtight Connector

Part Number: LT75-90

Part Description:

Provides the means of connecting flexible metallic conduit to boxes in wet or dry locations.

SKU: LT75-90 Category: 90° Liquidtight Connectors

Additional information

Trade Size	3/4
Material	-Body: CF8M (316 SS) -Gland Nut: 316 SS -Inside Ferrule: 316 SS -Locknut: 316 SS -Sealing Gasket: Neoprene -Sealing Ring: Polypropylene
Material	CF8M/316 SS
Weight/100 (lbs.)	61
Dimension A (in.)	1.7
Dimension B (in.)	1.07
Dimension C (in.)	3/4-14 NPT
Dimension D (in.)	0.79
Dimension E (in.)	2.35
Dimension F (in.)	2.56
Country of Origin	100% Made in USA

Manufactured in stainless steel to help prevent corrosion
Can be installed using ordinary hand tools and require little maintenance or repair
Provided in a bright, polished finish that does not require touch up or painting

Used in areas where corrosion is a concern:
